DURA-ACE – Front Hub – Rim Brake- Quick Release

With labyrinth and contact seals, Super Finishing cup and polished cone, and SHIMANO’s Digital Cone Bearing Adjustment System, the DURA-ACE HB-9000 is the world’s finest rim brake hub. Weighing in at 120 grams, it is perfect for custom road wheel builds.

PRODUCT SPECIFICATIONS

MODEL NO: HB-9000
SERIES: DURA-ACE 9000 Series
Color: Series color
Average weight: 120
Remarks: * Aero spoke hole available(18H/24H) ** Super Finishing
Brake type: Rim brake
Axle fixing method: Quick release
Flange distance (mm): 74
Offset (mm): 0
P.C.D. left / right (mm): 38
Spoke hole 24H:
Flange diameter (mm): 48.4
Internal grease sleeve:
O.L.D. (mm): 100
Seal: Labyrinth & Contact
Spoke hole_28H:
Spoke hole_32H:
Spoke hole_36H:
Radial lacing:
Quick release skewer length (mm)_133:
Digital adjustment system:
Color 1 Hub shell: Series color
Color 1 Quick release: Series color
